Specifications: Dell PowerVault 160T Tape Library User's Guide
file:///C|/Users/greshma_dhanarajan/Desktop/ug/specs.htm[5/16/2013 10:08:25 AM]
Table 8. Configuration Four Specifications
Height Width Depth Maximum Weight Maximum Distributed Load Maximum Point Load
77.4 in.
1965.9 mm
95.0 in.
2413.7 mm
38.3 in.
973.9 mm
3554 lb
1615.5 kg
140.5 lb/ft
2
687.2 kg/m
2
73 lb/in
2
5.1 kg/cm
2
Barcode Requirements
A barcode must use only uppercase letters A to Z and/or numeric values 0 to 9. Your library currently supports Code 39 type
barcode labels.
You will have the best scanning results if you use Dell-supplied barcode labels. If you want to print your own barcode labels,
ensure the labels meet the following requirements:
ANSI MH10.8M-1983 Standard
Number of digits: up to 16
Background reflection: greater than 25 percent
Print contrast: greater than 75 percent
Ratio: greater than 2.2
Module: 250 mm
Print tolerance: ± 57 mm
Additional Requirements
Length of the rest zones: 5.25 mm ± 0.25 mm.
No black marks should be present in the intermediate spaces or rest zones.
No white areas should be present on the bars.
