In Figure 4 all devices have been manually mapped. The new map locations appear in heavy black type in the
LUN/Device column. The previous (default) device map position of a remapped device is shown in gray type in
the Device column.
Figure 3. FC Host LUN Mapping Dialog Box (Default View)
6. Drag and drop the devices from the Device column to the appropriate LUN assignment in the LUN/Device column.
7. Select OK to save the mapping.
The FC Host map is automatically saved as part of the configuration.
Figure 4. FC Host Devices Mapped (Default View)
