281

SIGGEN – Signal Generator

This command selects/reports of the signal generator activation.

Command Form

: DEVICE SIGGEN [Channel Group Type Amplitude Frequency]

Argument

Type

Size

Values

Units

Channel

Channel

1

See Groups and Channels
(Null to query in text)

-

Group

Group

1

1, 3, 7 (I, M, L)

-

Type

Unsigned Integer

2

1 = Pink Noise
2 = White Noise
3 = Tone

-

Amplitude

Signed Float

4

-60.00 – 20.00

dB

Frequency

Unsigned Float

4

Type 1 – 2

0 (Null in text)

Hz

Type 3

20.00 – 20000.00

SIGGENEN – Signal Generator Enable

This command selects/reports of the signal generator activation.

Command Form

: DEVICE SIGGENEN [Value]

Argument

Type

Size

Values

Units

Value

Unsigned Integer

4

0 = Off
1 = On
2 = Toggle
(Null to query in text)

-

SIGGENSWEEP – Signal Generator Sweep

This command starts the signal generator with a tone and does a sweep. If Repeat is 0, the signal generator will
turn off after the sweep. If Repeat is 1, the signal generator will turn off after signal generator timeout. To stop
the sweep, send a SIGGENEN command with a 0. During the sweep, the box will send out updated SIGGEN
commands.

Command Form

:

DEVICE SIGGENSWEEP

Argument

Type

Size

Values

Units

Channel

Channel

1

See Groups and Channels

-

Group

Group

1

1, 3, 7 (I, M, L)

-

Amplitude

Signed Float

2

-60.00 – 20.00

dB

Start
Frequency

Unsigned Float

4

20.00 – 20000.00

Hz

End
Frequency

Unsigned Float

4

20.00 – 20000.00 (must be greater than the
start)

Hz

Increment
Frequency

Unsigned Float

4

1.00 – 20000.00

Hz

Rate

Unsigned Integer

2

10 – 2000 ms

Hz

Repeat

Unsigned Integer

2

0 = repeat off
1 = repeat on

-

SIGTOUT – Signal Generator Time Out

Sets the signal generator time out for the unit.

Command Form

: DEVICE SIGTOUT [Value]

Argument Type

Size

Values

Units

Value

Unsigned Integer

4

0 = Disable
1 – 30
(Null to query in text)

Min
