229

If an asterisk (*) is placed in the Device Type or Device ID fields, the command will apply to all units or all

devices respectively. For example, a command with a Device Type = 1 and a Device ID = * would apply the

command to all Converge 880 units. A command with a Device Type = * and a Device ID = 6 would apply the

command to all units with a Device ID of 6.

If a command specifies “(Null to query in text)” in its Value table, leave a blank in the command line to query the

current state of that value. For example, the command #12 MUTE 5 M would return the current mute

state of Mic 2 on an 880 unit with a Device ID of 0.

GROUPS AND CHANNELS

All serial commands use common alpha and numeric designators to reference channel groups, channel types,
and other command values. Also, different channel groups have different allowable channel ranges, as shown in
the following table.

Group

Alpha

Converge

Pro 880 and

SR 1212
Channel

Range

Converge

Pro TH20

Channel

Range

Converge

Pro 840T

Channel

Range

Converge

Pro 8i

Channel

Range

Converge

880T

Channel

Range

Converge

880TA

Channel

Range

Converge
SR 1212A

Channel

Range

Converge

Pro VH20

Channel

Range

Beam-

forming

Mic Array

Channel

Range

Inputs

I

1-12

1-2

1-8

1-12

1-12

1-12

1-12

1-2

N/A

Outputs

O

1-12

1-2

1-9 (9 is

the power

amp)

N/A

1-13 (13 is

the power

amp)

1-8

1-12

1-2

N/A

Mic Input

M

1-8

N/A

1-4

1-8

1-8

1-8

1-8

N/A

N/A

Beamforming

Mic Array

V

N/A

N/A

N/A

N/A

N/A

N/A

N/A

N/A

1

Amplifier

Output

J

N/A

N/A

N/A

N/A

N/A

1-4

1-4

N/A

N/A

Gating Group

G

1-4, A-F

N/A

1-4, A-F

1-4, A-F

1-4, A-F

1-4, A-F

1-4, A-F

N/A

A-F

Processing

P

A-F

N/A

A-D

A-F

A-F

A-F

A-F

N/A

N/A

Expansion
Bus Audio

Channels

E

O-Z, I-N

O-Z, I-N

O-Z, I-N

O-Z, I-N

O-Z, I-N

O-Z, I-N

O-Z, I-N

O-Z, I-N

O-Z, I-N

Line Inputs

L

9-12

1-2

5-8

9-12

9-12

9-12

9-12

1-2

N/A

Expansion

Bus

Reference

Channels

A

1-8

1-8

1-8

1-8

1-8

1-8

1-8

1-8

1-8

GPIO

Y

0

0

0

0

0

0

0

0

N/A

Matrix

X

0

0

0

0

0

0

0

0

0

Fader

F

1-4

N/A

1-4

N/A

1-4

N/A

N/A

N/A

N/A

Presets

S

1-32

1-32

1-32

1-32

1-32

1-32

1-32

1-32

N/A

Macros

C

1-255

1-255

1-255

1-255

1-255

1-255

1-255

1-255

N/A

Transmit

T

N/A

1

1

N/A

1

1

N/A

N/A

N/A

Receive

R

N/A

1

1

N/A

1

1

N/A

N/A

N/A

Virtual

Reference

B

1 – 4

N/A

1 – 4

N/A

1 – 4

1-4

N/A

N/A

N/A

Timed Events

Q

1-10

1-10

1-10

1-10

1-10

1-10

1-10

1-10

N/A

Web

W

0

0

0

0

0

0

0

0

N/A

PA Virtual

Reference

H

N/A

N/A

N/A

N/A

N/A

1-4

1-4

N/A

N/A

VoIP Transmit

K

N/A

N/A

N/A

N/A

N/A

N/A

N/A

1

N/A

VoIP Receive

Z

N/A

N/A

N/A

N/A

N/A

N/A

N/A

1

N/A

USB Transmit

D

N/A

N/A

N/A

N/A

N/A

N/A

N/A

N/A

N/A

USB Receive

U

N/A

N/A

N/A

N/A

N/A

N/A

N/A

N/A

N/A
