Metrohm tiBase 1.1 - Manual (Page 298)

4.8 Curves subwindow
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
290 ￭￭￭￭￭￭￭￭
tiBase 1.1
Show endpoints
Show endpoints
on | off (Default value: on)
If this check box is activated then the endpoints found will be shown on
the curve by the symbol ♦ and labeled with EP# (potentiometric end-
point), BP# (break point), FP# (fixed endpoint), HP (HNP), MI (minimum
value) or MA (maximum value).
Automatic EPs
Selection of the color for automatically set endpoints.
Selection 13 colors | black
Default value black
Manual EPs
Selects the color for manually set endpoints.
Selection 13 colors | pink
Default value pink
Show evaluation lines
Show evaluation lines
on | off (Default value: off)
If this check box is activated the evaluation lines (tangents, auxiliary lines)
will be shown.
Tangents
Selection of the color for the tangents and auxiliary lines.
Selection 13 colors | light green
Default value light green
Auxiliary lines
Selection of the color for the auxiliary lines.
Selection 13 colors | blue
Default value blue
4.8.3.6 Curve properties - Measuring point list
Dialog window: Database ▶ Curves ▶ Properties curves # ▶ Options
Parameters for showing the measuring point list.
