The fewer the number of inputs, outputs and signal paths, the fewer the
number of permutations that require testing. However, a single safety function
should not be split into separate blocks; such a division is likely to lead to the
introduction of errors during maintenance activities.
The interaction between the individual software blocks shall be minimized.
Where interaction is necessary, it should be kept as simple as possible, for
example a single shutdown initiation signal.
Each safety function shall be responsible for the control of the corresponding
outputs. Sharing of outputs between functions shall not be permitted.
The use of these function blocks in a safety certified system is only
permitted once they have been tested for correct operation.
The new or previously untested function may be:
a generic function block, which forms part of the Workbench, but has not
previously been subject to the level of testing defined herein, or
a project-specific function block, which is written to meet the needs of a
particular feature within an application program, and may comprise a
number of generic function blocks or other program functions.
Individual Safety Related Functions
The AADvance Workbench allows the definition of up to 250 individual
programs within a single project. This facility should be exploited to enable the
allocation of individual safety related functions to separate programs. Where
such programs contain independent logic paths, these should be investigated to
determine if they are separate safety functions. Where they are separate, it is
recommended that these be further allocated to their own program, subject to
conforming to the recommendation to minimizing the coupling between
programs.
Cases should be looked for that allow the creation of individual logic paths by
repeating small sections of logic rather than fanning out the resultant signal(s).
