User Quick Reference Table E-1
A
PPENDIX
E
User Quick Reference Table
No. Parameter Name Default User Value/Date
P-00 Minimum Speed 0
P-01 Maximum Speed 60
P-02 Motor Overload Current 100% of rated drive amps
P-03 Reverse Disable 0
P-04 Auto Restart Attempts 0
P-05 Current Limit 150
P-10 Start Control 2
P-11 Configurable Input 2 (A) / 1 (B) / 0 (C)
P-12 Configurable Output 0
P-13 Configurable Output Level 0
P-20 Main Speed Reference 0
P-21 Alternate Speed Reference 1
P-22 Analog Input 1 Offset 0.0 (model A, C only)
P-23 Analog Input 1 Gain 100.0 (model A, C only)
P-24 Analog Input 2 Offset 0.0 (model C only)
P-25 Analog Input 2 Gain 100.0 (model C only)
P-26 Process Proportional Gain 0 (model C only)
P-27 Process Integral Gain 0 (model C only)
P-28 Process Reference 0 (model C only)
P-29 Process Operation 0 (model C only)
P-30 Acceleration Time 1 5.0
P-31 Deceleration Time 1 5.0
P-32 Acceleration Time 2 10.0
P-33 Deceleration Time 2 10.0
P-34 Stop Control 0
P-35 DC Brake Current 50
P-36 DC Brake Time at Stop 0.5
P-37 Avoidance Frequency 0
P-38 Avoidance Frequency Band 0
P-40 Internal/Jog Frequency 60.0
P-41 Preset Speed 1 2.5
P-42 Preset Speed 2 5.0
P-43 Preset Speed 3 10.0
P-44 Preset Speed 4 20.0
P-45 Preset Speed 5 30.0
P-46 Preset Speed 6 40.0
P-47 Preset Speed 7 50.0
P-48 Preset Speed 8 60.0
P-50 Base Voltage 230 / 460
P-51 Base Frequency 60
P-52 Breakpoint Voltage 0
P-53 Breakpoint Frequency 0
P-54 Boost Voltage 11 / 23
P-55 Auto Torque Boost 3.0
P-60 Reset to Defaults 0
P-61 Program Password OFF
P-62 Speed Display Units 0
P-63 Analog Input Display Units 0
P-64 Carrier Frequency 2.0
