D-2 Installing and Operating the SP200 AC Drive
Reactor
Drive Rating
1000 V
Motor
Limit
SP200 Drive Limit
Input
Volts HP (kW)
Shielded Cable or Wires in Conduit Unshielded Cable
2 kHz 4 kHz 6 kHz 8 kHz 2 kHz 4 kHz 6 kHz 8 kHz
ft m ft m ft m ft m ft m ft m ft m ft m ft m
None 120 / 240 0.5 (0.37) — — 250 76 250 76 250 76 200 61 600 183 600 183 600 183 600 183
120 / 240 1.0 (0.75) — — 500 152 500 152 400 122 300 91 600 183 600 183 600 183 600 183
120 / 240 1.5 (1.1) — — 600 183 600 183 500 152 300 91 600 183 600 183 600 183 600 183
240 2.0 (1.5) — — 600 183 600 183 500 152 300 91 600 183 600 183 600 183 600 183
460 0.5 (0.37) 50 15 100 30 100 30 100 30 90 27 175 53 175 53 175 53 150 46
460 1.0 (0.75) 25 8 120 37 100 30 100 30 100 30 300 91 300 91 300 91 300 91
460 2.0 (1.5) 20 6 220 67 180 55 180 55 100 30 400 122 400 122 400 122 400 122
3 % at
Drive 120 / 240 0.5 (0.37) — — 400 122 300 91 300 91 100 30 600 183 600 183 600 183 600 183
120 / 240 1.0 (0.75) — — 500 152 300 91 300 91 200 61 600 183 600 183 600 183 600 183
120 / 240 1.5 (1.1) — — 600 183 400 122 300 91 200 61 600 183 600 183 600 183 600 183
240 2.0 (1.5) — — 600 183 400 122 300 91 200 61 600 183 600 183 600 183 600 183
460 0.5 (0.37) 15 5 120 37 100 30 100 30 90 27 200 61 200 61 200 61 150 46
460 1.0 (0.75) 40 12 180 55 140 43 100 30 100 30 600 183 600 183 600 183 400 122
460 2.0 (1.5) 80 24 220 67 200 61 170 52 130 40 600 183 600 183 600 183 200 183
3 % at
Motor 120 / 240 0.5 (0.37) — — 300 91 280 85 280 85 280 85 600 183 600 183 600 183 600 183
120 / 240 1.0 (0.75) — — 600 183 600 183 500 152 400 122 600 183 600 183 600 183 600 183
120 / 240 1.5 (1.1) — — 600 183 600 183 500 152 300 91 600 183 600 183 600 183 600 183
240 2.0 (1.5) — — 600 183 600 183 500 152 300 91 600 183 600 183 600 183 600 183
460 0.5 (0.37) 300 91 100 30 100 30 100 30 90 27 175 53 175 53 175 53 150 46
460 1.0 (0.75) 300 91 120 37 100 30 100 30 100 30 300 91 300 91 300 91 300 91
460 2.0 (1.5) 300 91 200 61 200 61 200 61 170 52 400 122 400 122 400 122 400 122
