Wire Input Power and Output Power 4-1
C
HAPTER
4
Wire Input Power and Output Power
Observe the following guidelines when wiring AC power:
• The recommended temperature rating for power wire is 75 ° C or greater.
• The terminal blocks accept up to 4 mm
2
(12 AWG) wire.
• The recommended tightening torque is 1.35 newton-meters (12 in-lb).
Verify that the input power to the drive corresponds to the drive voltage and frequency
and that the input supply is of sufficient capacity to support the input current
requirements. Refer to Appendix A, Technical Specifications.
Size the AC line conductors for the drive rating and in accordance with all applicable
local and national codes.
Ensure that motor cables conform to the recommendations in Appendix D, Motor
Cable Recommendations.
Procedures for wiring input power to the drive and output power to the motor are
described in section 4.1.
!
ATTENTION: This equipment is at line voltage when AC power is
connected. Disconnect and lockout all ungrounded conductors of the AC
power line before working on the unit. Failure to observe this precaution
could result in severe bodily injury or loss of life.
ATTENTION: The user is responsible for conforming with all local and
national codes applicable to the grounding of this equipment. Failure to
observe this precaution could result in severe bodily injury or loss of life.
ATTENTION: If the distribution system capacity exceeds the drive’s
maximum symmetrical fault short-circuit current of 100,000 amps,
additional impedance must be added to the AC line supplying the drive
to limit available current in the event of a fault. Failure to observe this
precaution could result in damage to, or destruction of, the equipment.
