A-2 Installing and Operating the SP200 AC Drive
Operating Performance
• Input frequency resolution: 0.4% analog; 0.1 Hz digital
• Output frequency resolution: 0.1%
• Output voltage regulation: 3%
• Power dip control ride through time: 100 msec minimum
Drive Power Loss
• Typical Full load power loss:
Ambient Conditions
• Operating temperature: 0
°
C to 50
°
C (32
°
F to 122
°
F)
• Storage temperature: -40
°
C to 85
°
C (-40
°
F to 185
°
F)
• Humidity: 0 to 95% non-condensing
• Elevation: 1000 meters (3300 ft) maximum without derating. For every 91.4
meters (300 ft) above 1000 meters, derate the current by 1%. Above 3000 meters,
(10,000 ft), consult your Reliance Electric Sales Office.
Dimensions
• Height: 139.8 mm (5.5 in)
• Width: 72.0 mm (2.835 in)
• Depth: 138.8 mm (5.47 in)
Standards and Approvals
• UL508C
• CSA22.2
• EN50178, EN60204-1 for Low Voltage Directive
• EN50081-1, EN50082-2, parts of EN61800-3 for EMC
Input Voltage Unit HP Typical Power Dissipation (W)
2 kHz 4 kHz 6 kHz 8 kHz
100 -120, 1-phase 0.5
1.0
1.5 25
45
70 27
48
73 28
50
77 30
52
80
200 - 240, 1-phase 0.5
1.0
1.5
2.0 25
45
70
75 27
48
73
80 28
50
77
85 30
52
80
90
200 - 240, 3-phase 0.5
1.0
2.0 25
40
70 27
43
75 28
45
80 30
47
85
380 - 460, 3-phase 0.5
1.0
2.0 25
30
50 30
37
60 35
44
72 40
50
85
