7-2 Installing and Operating the SP200 AC Drive
7.1 Program Parameters
Program parameters are used to configure drive operation.
Important: Some parameters can be edited when the drive is running. Note the
access code listed for each parameter (RO = read only; RW = read/write).
The code listed indicates whether the parameter can be edited when the
drive is running. All program parameters can be edited when the drive is
not running.
7.1.1 Protection Parameters (Group 0)
P-00 Minimum Speed Model
A B C
Use this parameter to set the lowest
frequency the drive will output. Parameter Range: 0 to Maximum Speed (Hz) X X X
Default Setting: 0 X X X
Running Access: RO
P-01 Maximum Speed Model
A B C
Use this parameter to set the
highest frequency the drive will
output. Parameter Range: Minimum Speed to 240 (Hz) X X X
Default Setting: 60 X X X
Running Access: RO
P-02 Motor Overload Current Model
A B C
Use this parameter to set the motor
overload protection level (in amps) so
that constant operation above this
value will result in a motor overload
fault, based on the magnitude and Parameter Range: 20% to 200% of the rated drive
current in amps (x.x A) X X X
Default Setting: 100% of the rated drive current X X X
Running Access: RW
time of the condition. For example, a load condition equal to 150% of this setting will cause a fault in
approximately one minute. Smaller overload conditions will require more time to fault. Larger overload
conditions will require less time to fault. Set this parameter value to the full load amp rating of the motor
(usually specified on the motor nameplate).
