7-6 Installing and Operating the SP200 AC Drive
P-11 Configurable Input (continued)
Model C:
For 3-wire control, the configurable input always operates as a stop input, regardless of the value of parameter
P-11 (Configurable Input Select). The configurable input must be maintained on to enable the drive to run. If
the configurable input is off, the drive will stop according to the specified stop mode. A falling edge of this input
is used to reset a fault condition.
For 2-wire control, the following functions are supported:
When P-11 is set to: Then the configurable input works as follows:
0 (Function Loss) When the configurable input is OFF, the drive will stop and a Function
Loss (FL) error will be displayed.
1 (Disabled) When the configurable input is ON, the drive will run in the reverse
direction.
2 (Jog) When the configurable input is ON, the drive will jog at the Internal /
Jog Frequency (P-40) in the forward direction.
3 (Alternate Speed Reference) When the configurable input is ON, the drive will use the value of
parameter P-21 (Alternate Speed Reference) as the source of the
command frequency. See figure 7.1 or 7.2 for more information
4 (N.C. Coast to Stop) When the configurable input is OFF, the drive will coast to stop.
5 (Secondary Accel/Decel) When the configurable input is ON, the drive will use parameters
P-32 (Acceleration Time 2) and P-33 (Deceleration Time 2) for the
accel and decel times.
P-12 Configurable Output Model
A B C
Use this parameter to define the way
the Configurable Output works. Parameter Range: 0 = No Fault
1 = No Fault or Auto-Restarting
2 = Run
3= At Frequency
4 = Above Frequency
5 = Above Current Level X
X
X
X
X
X X
X
X
X
X
X X
X
X
X
X
X
Default Setting: 0 X X X
Running Access: RW
Drive models A and B (Single Channel Analog and Preset Speed) have one normally open and one normally
closed contact (Form C). Drive model C (Dual Channel Analog) has a single normally open contact (Form A).
The condition that drives this relay to turn on or off is programmable, as summarized in the following table.
If P-12 is set to: Then the normally open relay contact closes when...
0 (No Fault) (default) the drive is not faulted.
1 (No Fault or Auto-Restarting) the drive is not faulted or is auto-restarting.
2 (Running) the drive is running.
3 (At Frequency) the output frequency is equal to the commanded frequency.
4 (Above Frequency) the output frequency is greater than a specified level.
5 (Above Current Level) the output current is greater than a specified level.
