Editing Drive Parameters 7-5
.
P-11 Configurable Input (continued)
Model B:
When P-11 is set to: Then the configurable input works as follows:
1 (Preset Speed) The configurable input is combined with Preset 1 and Preset 2 to
select the command frequency from a set of preset speeds as shown
in the table below. If P-11
≠
1, then only preset frequencies 1 through
4 can be selected.
Terminal 8
(Configurable
Input)
Terminal 7
(Preset 2)
Terminal 6
(Preset 1)
Preset
Frequency
OFF OFF OFF Preset Frequency 1
OFF OFF ON Preset Frequency 2
OFF ON OFF Preset Frequency 3
OFF ON ON Preset Frequency 4
ON OFF OFF Preset Frequency 5
ON OFF ON Preset Frequency 6
ON ON OFF Preset Frequency 7
ON ON ON Preset Frequency 8
2 (Jog) When the configurable input is ON, the drive will jog at the Internal /
Jog Frequency (P-40) in the direction specified by the Reverse input.
3 (Alternate Speed Reference) When the configurable input is ON, the drive will use the value of
parameter P-21 (Alternate Speed Reference) as the source of the
command frequency. See figure 7.1 or 7.2 for more information
4 (N.C. Coast to Stop) When the configurable input is OFF, the drive will coast to stop.
5 (Secondary Accel/Decel) When the configurable input is ON, the drive will use parameters
P-32 (Acceleration Time 2) and P-33 (Deceleration Time 2) for the
accel and decel times.
