Using the Local Keypad 6-3
6.3 Step-by-Step Keypad Operation
The following table provides detailed steps for keypad operation.
Table 6.3 – Keypad Operation
Desired Action User Steps
Start the unit
1
Press the green key to start the drive.
Stop the unit
Press the red key to stop the drive.
Increment the local
speed reference
While in display mode (PROG LED is off), press the key to increase speed.
Decrement the local
speed reference
While in display mode (PROG LED is off), press the key to decrease speed.
View the value of the
present display
parameter While in display mode (PROG LED is off), the value of the present display
parameter is normally displayed.
View the number of
the present display
parameter
While in display mode, press and release the key once. The present display
parameter number will be displayed for 2 seconds. The display will then return to
the present parameter value.
Increment the display
parameter number
While in display mode, press the key until the desired parameter is displayed.
Following a 2 second delay, the parameter value will be displayed.
Increment the
program parameter
number 1. Press the PROG key to enter program mode.
2. Press the key until the desired number is displayed.
Decrement the
program parameter
number 1. Press the PROG key to enter program mode.
2. Press the key until the desired number is displayed.
Increment the current
program parameter
value 1. Press the PROG key to enter program mode.
2. Press the key while the desired program parameter number is displayed.
3. Press the key until the desired value is displayed.
Decrement the current
program parameter
value 1. Press the PROG key to enter program mode.
2. Press the key while the desired program parameter number is displayed.
3. Press the key until the desired value is displayed.
Clear faults
Press the red key.
1. For the key to work, a connection must be present between terminals 2 and 3. In addition, parameter P-10 must be set to 1.
