Programming Reference

4-27

Jog reference is independent of any other speed reference. Unlike the run speed

reference, the jog speed reference cannot be adjusted using the ▲ or ▼ keys.

The time the motor takes to make any speed increase is directly proportional to the

value in this parameter.

P.020 Jog Speed Reference

This parameter is the

speed reference for

the drive when JOG

is selected.

Parameter Range:

Minimum Speed (P.003) to Maximum Speed (P.004)

Default Setting:

5.0 Hz (V/Hz)

150 RPM (vector)

Parameter Type:

Tunable

Refer also to parameters:

P.003 Minimum Speed

P.004 Maximum Speed

P.021 Jog Ramp Accel Time

For V/Hz regulation,

this parameter

specifies the amount

of time it takes the

motor to ramp from

zero speed to

Maximum Speed

(P.004) when JOG is

selected.

For vector regulation,

this parameter

specifies the amount

of time it takes the

motor to ramp from

zero speed to Motor

Top Speed (U.017)

when JOG is

selected.

Parameter Range:

1.0 to 999.9 seconds (V/Hz)

0.1 to 999.9 seconds (vector)

Default Setting:

20.0

Parameter Type:

Tunable

Refer also to parameters:

P.004 Maximum Speed

U.017 Motor Top Speed
