4-14 GV3000/SE AC Drive Software Reference, Version 6.06
4.6.2 Second Menu General Parameter Descriptions (P.007 to P.099)
An unasserted (open) or asserted (closed) input will select the input functions as
shown in table 4.2. If a function is not configured, the unasserted (open) state will be
applied.
P.007 Terminal Strip Digital Inputs Configure
The GV3000/SE
drive provides
multiple
configurations of
digital inputs 6, 7,
and 8 on the terminal
strip. This parameter
determines how
these inputs are
used.
The P.008 (Terminal
Strip Speed
Reference Source)
selection will limit the
selection of P.007
because the P.008
selection may use
one or more of digital
inputs 6 through 8.
Parameter Range: Preset Configurations of Inputs 6, 7, and 8
Digital Input 6 Digital Input 7 Digital Input 8
(Terminal 19) (Terminal 18) (Terminal 17)
0 = FWD/REV RAMP 1/2 REM/LOC
1 = Not used FWD/REV RAMP 1/2
2 = Not used FWD/REV REM/LOC
3 = Not used RAMP 1/2 REM/LOC
4 = Not used Not used FWD/REV
5 = Not used Not used RAMP 1/2
6 = Not used Not used REM/LOC
7 = Not used Not used Not used
8 * = FWD/REV TRQ/SPD REM/LOC
9* = Not used TRQ/SPD REM/LOC
10* = Not used TRQ/SPD FWD/REV
11* = Not used TRQ/SPD RAMP 1/2
12* = Not used Not used TRQ/SPD
* Vector regulation only.
Default Setting: 0
Parameter Type: Configurable
Refer also to parameters: P.008 Terminal Strip Speed Reference Source
!
ATTENTION: If a maintained start contact is used when the control
source = rE, switching from local to remote from the terminal strip will
cause power to be applied to the motor if the remote start contact is
closed. Stay clear of rotating machinery in this case. Failure to observe
this precaution could result in bodily injury.
Table 4.2 – Function Selection for Digital Inputs 6, 7, and 8
Input Open (Unasserted) Closed (Asserted)
FWD/REV Forward Reverse
RAMP 1/2 Ramp 1 Ramp 2
REM/LOC Remote Local
TRQ/SPD Torque Speed
