4Ć28

4.7.2

Output Parameters for the Mask Compare Instruction

This table lists the outputs for the MSK instruction. To use these outputs, connect them

to a contact, coil, or Boolean input.

Parameter

Description

ENO

Use this output as the input to another instruction for easily

chaining multiple instructions. This output follows the state

EN unless an error occurs.

Q

When the instruction is enabled, this output is true after the

bit mask has been applied to In1 and In2 and the results

were compared and determined to be equal.
Otherwise, Q is false.
