Rockwell Automation AutoMax Enhanced Ladder Language Reference Manual User Manual
Page 265
12Ć13
12.3
Listing of Base Addresses for Each Supported Slot in the AutoMax Chassis
Slot
Hex Address Range
Slot
Hex Address Range
4
240000 to 24FFFF
10
2A0000 to 2AFFFF
5
250000 to 25FFFF
11
2B0000 to 2BFFFF
6
260000 to 26FFFF
12
2C0000 to 2CFFFF
7
270000 to 27FFFF
13
2D0000 to 2DFFFF
8
280000 to 28FFFF
14
2E0000 to 2EFFFF
9
290000 to 29FFFF
15
2F0000 to 2FFFFF
