12Ć6

12.1.3

Defining the Amount of I/O Data to Read

To read:

In the Option

field, enter:

In the Register/address

field, enter:

Result:

byte

1

data's location

a byte is read

double byte
Note: Only use this

option to read data

from modules that only

support an 8Ćbit

Multibus access.

2

data's location

The low byte is read

first and then the high

byte.

integer (16Ćbits)
Note: Use this option to

read data from modules

that support AutoMax

addressing and data

conventions.

3

data's location as an

even address

A 16Ćbit word is read

from the designated

address.

double integer (32Ćbits) 4

data's location as an

even address

A 32Ćbit word is read

from the designated

address in this order:
D MS 16Ćbit word
D LS 16Ćbit word
