3Ć4
3.1.1 Input Parameters for the RTO Instruction
This table lists the inputs for the RTO instruction and the variable type and data
type/range that each input supports.
Parameter Description Variable Type Data Type/Range
EN While this input is true, the instruction executes. When this
input is false, the instruction is not executed and ENO is
false.
Connect a Boolean input or output.
TR To reset the counter to 0, set this input to true. Output Q
becomes false.
Connect a Boolean input or output.
Name Enter the name of the timer variable you want to use for
this timer.
data structure timer
See also About
Timer Variables"
TPreset Enter the value that Elapsed must reach before the
instruction sets output Q. Enter a value in increments of
0.01 seconds up to 248.5 days.
This value is stored in name.TPreset.
constant double integer
(0 to 2147483647)
0 to 248.5 days in
0.01 second intervals
