4Ć20

4.5.2

Output Parameters for the Less Than Instruction

This table lists the outputs for the LT instruction. To use these outputs, connect them to

a contact, coil, or Boolean input of another instruction.

Parameter

Description

ENO

Use this output as the input to another instruction for easily

chaining multiple instructions. This output follows the state of

EN unless an error occurs.

Q

This output is set true when the following conditions occur:
D the instruction is enabled
D In1 is less than In2
D if In3 is used, In2 is less than In3
Otherwise, Q is false.
