Rockwell Automation AutoMax Enhanced Ladder Language Reference Manual - Manual (Page 162)

8Ć4
8.1.2 Output Parameters for the Move Source Data to Destination Instruction
This table lists the outputs for the MOVE instruction and the variable type and data
type/range that each output supports.
Parameter Description Variable Type Data/Type Range
ENO Use this output as the input to another instruction for
easily chaining multiple instructions. This output follows
the state of EN unless an error occurs.
Connect a contact, coil, or Boolean input to
another instruction.
Out Enter the variable within which you want to store the value
copied from In. Out is the destination of the move
operation.
D simple
D element of an array D integer
D double integer
D timer
(name.TPreeset
and
name.Elapsed)
D counter
(name.CPreset
and name.Current)
