11 errors caused by the relay instructions – Rockwell Automation AutoMax Enhanced Ladder Language Reference Manual User Manual
Page 33

1Ć17
1.11
Errors Caused by the Relay Instructions
These errors can occur when you are using the relay instructions in a program. They
are logged in the error log.
If this error occurs:
Then:
Do the following:
The bit number is negative.
Bit 0 of the variable will be used for
the instruction's operation.
Specify a number of 0Ć15 for integers
and 0Ć31 for double integers.
The bit number is too large. The largest bit number of the variable
will be used for the instruction's
operation.
Specify a number of 0Ć15 for integers
and 0Ć31 for double integers.
The array index is negative. Element 0 of the array variable will be
used for the instruction's operation.
Specify a valid array element.
The array index is too large. The largest element number of the
array variable will be used for the
instruction's operation.
Specify a valid array element.
