5Ć14

5.4.2

Output Parameters for the Modulo Instruction

This table lists the outputs for the MOD instruction and the variable type and data

type/range that each output supports.

Parameter

Description

Variable Type

Data Type/Range

ENO

Use this output as the input to another instruction for

easily chaining multiple instructions. This output follows

the state of the EN input unless an error occurs.

Connect a contact, coil, or a Boolean input to

another instruction.

Out

This output contains the remainder of the division

operation.

D simple
D element of an array

D integer
D double integer
D timer (name.TPreset

and name.Elapsed)

D counter

(name.CPreset and

name.Current)
