Rockwell Automation AutoMax Enhanced Ladder Language Reference Manual User Manual
Page 76
4Ć16
4.4.2
Output Parameters for the Less Than Or Equal To Instruction
This table lists the outputs for the LE instruction. To use these outputs, connect them to
a contact, coil, or Boolean input to another instruction.
Parameter Description
ENO
Use this output as the input to another instruction for easily
chaining multiple instructions. This output follows the state of
EN unless an error occurs.
Q
This output is set true when all of the following conditions occur:
D the instruction is enabled
D In1 is less than or equal to In2
D if In3 is used, In2 is less than or equl to In3
Otherwise, Q is false.
