11Ć3
11.1.1 Input Parameters for the Set Event Instruction
Parameter Description
EN While this input is true, the instruction executes. When this
input is false, the instruction is not executed and ENO is
false.
Connect a Boolean input or output.
Event Name Enter the name of the software event you want to use.
I MPORTANT
Software Events are used only in the Event Name input of
SET instructions. When you specify a new name in the
Event Name input of the Set Event instruction, the Editor
automatically defines it as a Software Event.
11.1.2 Output Parameters for the Set Event Instruction
Parameter Description
ENO Use this output as the input to another
instruction for easily chaining multiple
instructions. This output follows the state of
the EN input.
Connect a Boolean input or a coil.
