Rockwell Automation AutoMax Enhanced Ladder Language Reference Manual User Manual
Page 202
9Ć28
9.7.2
Errors Caused by the Circular Rotate Bits Left, Circular Rotate Bits Left
on Transition, Circular Rotate Bits Right, and Circular Rotate Bits Right
on Transition Instructions
This error can occur when you are using the ROL, RL, ROR, and RR instructions. It is
logged in the error log.
If this error occurs:
Then:
Do the following:
D The number of bits to
rotate is negative.
D The number of bits to
rotate is too large.
D No bits are rotated
D ENO is set to
ERROR_ENO
D Out reflects least
significant bit of In
Make sure that N is
within the allowable
range for the data type
used for In.
