5Ć6
5.2.1 Input Parameters for the Add Instruction
This table lists the inputs for the Add instruction and the variable type and data
type/range that each input supports.
Parameter Description Variable Type Data Type/Range
EN When this input is true, the instruction executes. When this
input is false, the instruction is not executed, and ENO is
false.
Connect a Boolean input or output.
In1
In2
In3 Enter the variables or constants you want to add. You must
specify values for at least In1 and In2. In3 is optional.
D simple
D constant
D element of an array D integer
D double integer
D timer
(name.TPreset
and
name.Elapsed)
D counter
(name.CPreset
and name.Current)
