10Ć42
10.7.4 Errors Caused by the Array Shift Up and Array Shift Down Instructions
These errors can occur when you are using the ASU and ASD instructions in a
program. They are logged in the error log.
If this error occurs: Then: Do the following:
The array index is negative. ENO is set according to
ERROR_ENO, and element
zero of the array is used for
the instruction's operation.
Specify a valid array element.
The array index is too large. ENO is set according to
ERROR_ENO, and the last
element of the array is used
for the instruction's
operation.
Specify a valid array element.
