8Ć7
8.2.1 Input Parameters for the Move Bits Between Integers/Double Integers Instruction
This table lists the inputs for the MVB instruction and the variable type and date
type/range that each input supports.
Parameter Description Variable Type Data/Type Range
EN While this input is true, the instruction executes. When this
input is false, the instruction is not executed and ENO is
false.
Connect a Boolean input or output.
In Enter a constant or variable from which you want to move
bits, the source of the bit move operation.
D simple
D constant
D element of an array D integer
D double integer
D timer
(name.TPreset and
name.Elapsed)
D counter
(name.CPreset
and name.Current)
In_Bit Enter the number of the bit within In from which the
copying should start.
integer (0 31)
Out_Bit Enter the number of the bit within Out that the instruction
copies the bits to.
integer (0Ć31)
Length Enter the quantity of bits to be moved from In to Out.
When defining a length, keep in mind the following:
D Bits written to Out that extend beyond Out's data type
boundary are lost.
D Bits you copy from In that extend beyond bit 15 for
integers and bit 31 for double integers are set to 0.
integer (0Ć32)
