Chapter 2 Installation
Required Tools These tools are required for panel installation:
•
Panel cutout tools
•
Small, slotted screwdriver
•
Torque wrench (lb•in) for tightening the mounting clips on the
PanelView Plus 700 to 1500 and PanelView Plus CE terminals
Clearances Allow adequate clearance around the terminal, inside the enclosure,
for adequate ventilation. Consider heat produced by other devices in
the enclosure. The ambient temperature around the terminals must be
between 0…55 °C (32…131 ºF).
Cutout Dimensions Use the full size template shipped with your terminal to mark the
cutout dimensions.
Clearance Area 400 and 600 Terminals 700 to 1500 Terminals
Top 51 mm (2 in.) 51 mm (2 in.)
Bottom 102 mm (4 in.) 51 mm (2 in.)
Side
(1)
(1) Minimum side clearance for insertion of memory card and cable wiring is 102 mm (4 in.).
25 mm (1 in.) 25 mm (1 in.)
Back None 25 mm (1 in.)
Terminal Type Height mm (in.) Width mm (in.)
PanelView Plus 400 and 600 Terminals
400 Keypad or Keypad and Touch 123 (4.86) 156 (6.15)
600 Keypad or Keypad and Touch 142 (5.61) 241 (9.50)
600 Touch 123 (4.86) 156 (6.15)
PanelView Plus and PanelView Plus CE 700 to 1500 Terminals
700 Keypad or Keypad and Touch 167 (6.57) 264 (10.39)
700 Touch 154 (6.08) 220 (8.67)
1000 Keypad or Keypad and Touch 224 (8.8) 375 (14.75)
1000 Touch 224 (8.8) 305 (12.00)
1250 Keypad or Keypad and Touch 257 (10.11) 390 (15.35)
1250 Touch and 1250 High-bright Touch 257 (10.11) 338 (13.29)
1500 Keypad or Keypad and Touch 305 (12.00) 419 (16.50)
1500 Touch 305 (12.00) 391 (15.40)
