Communication port isolation – Rockwell Automation 2711P PanelView Plus Terminal User Manual User Manual
Page 169
Publication 2711P-UM001J-EN-P - November 2009
169
Terminal Connections Chapter 7
Communication Port
Isolation
The PanelView Plus and PanelView Plus CE terminals contain integral
and modular (externally attached) communication ports. Some of
these ports contain electrical isolation depending on the catalog
number of the terminal or communication module.
Integral Communication Port Isolation
400 and 600 Modular Communication Port Isolation
700 to 1500 Modular Communication Port Isolation
Communication Port
400 and 600 Terminal
700 to 1500 Terminal
RS-232
Nonisolated
Isolated
USB
Nonisolated
Nonisolated
Ethernet
Isolated
Isolated
Communication Port
Module
Isolation
RS-232
2711P-RN22C
Isolated
DH-485
2711P-RN3
Nonisolated
DH+
2711P-RN8
Isolated
Remote I/O
2711P-RN1
Isolated
DeviceNet
2711P-RN10C
Isolated
ControlNet
2711P-RN15C
Isolated
(1)
(1)
NAP port is nonisolated.
Communication Port
Module
Isolation
DH-485
2711P-RN6
Isolated
DH+
2711P-RN6
Isolated
Remote I/O
2711P-RN6
Isolated
DeviceNet
2711P-RN10H
Isolated
ControlNet
2711P-RN15S
Isolated
