226 Publication 2711P-UM001J-EN-P - November 2009
Appendix A Specifications
Display
Vibration 10…57 Hz, 0.012 pk-pk displacement
57…500 Hz, 2 g pk acceleration
Enclosure Ratings NEMA Type 12, 13, 4X (Indoor use only),
IP54, IP65
Airborne Contaminants For PVP/PVP-CE conformal-coated PCBA
level products:
ANSI/ISA S71.04 - 1985 Severity Level G3
EN60654-4:1998 Class 3
Attribute Value
Display type
400 and 600 grayscale
400…1500 color
Grayscale passive matrix, film compensated
super-twist nematic (FSTN)
Color active matrix, thin-film transistor (TFT)
with liquid crystal display (LCD)
Display size, diagonal
400 grayscale
400 color
600
700
1000
1250 and 1250 high-bright
1500
3.8 in.
3.5 in.
5.5 in.
6.5 in.
10.4 in.
12.1 in.
15.0 in.
Display area (WxH)
400 grayscale
400 color
600 grayscale and color
700
1000
1250 and 1250 high-bright
1500
77 x 58 mm (3.0 x 2.3 in.)
71 x 53 mm (2.8 x 2.1 in.)
112 x 84 mm (4.4 x 3.3 in.)
132 x 99 mm (5.2 x 3.9 in.)
211 x 158 mm (8.3 x 6.2 in.)
246 x 184 mm (9.7 x 7.2 in.)
304 x 228 mm (12.0 x 9.0 in.)
Resolution
400 grayscale and 400 color
600
700
1000
1250 and 1250 high-bright
1500
320 x 240
320 x 240
640 x 480
640 x 480
800 x 600
1024 x 768
Luminance (typical)
400 grayscale
400 color
600
700 to 1500
1250 high-bright
120 cd/m
2
Nits
200 cd/m
2
Nits
300 cd/m
2
Nits
300 cd/m
2
Nits
1000 cd/m
2
Nits
