Rockwell Automation 2711P PanelView Plus Terminal User Manual User Manual
Page 177
Publication 2711P-UM001J-EN-P - November 2009
177
Terminal Connections Chapter 7
DH+ Status Indicator
DH-485 Status Indicator
Remote I/O Scanner Mode Status Indicator
Condition
Indication
Off
Channel is not online.
Blinking green
Device is only node on the network.
Solid green
Device is online and receiving token.
Blinking red
Duplicate node.
Solid red
Failed selftest.
Condition
Indication
Off
Channel is not online.
Blinking green
Device is only node on the network.
Solid green
Device is online and receiving token.
Blinking red
Parity error.
Solid red
Failed selftest.
Condition
Indication
Off
Channel is not online.
Blinking green
At least one but not all adapters in
the scanlist are not responding.
Solid green
All adapters in the scanlist are
responding.
Blinking red
None of the adapters in the scanlist
are responding.
Solid red
Failed selftest.
