68
Rockwell Automation Publication 2080-UM005A-EN-E - December 2013
Chapter 8
Using the Micro800 Remote LCD
The controller limits certain operations according to controller mode, as shown
in the following table.
View and Edit Variable Values through the Remote LCD
Go to the 2080-REMLCD configuration window in Connected Components
Workbench. Click LCD Variables and select which variables you would like to
edit through the Remote LCD.
Main Menu Items
Menu Item
Description
I/O Status
Shows the status of the local I/O.
Mode switch
Change the mode switch selection.
Variables
View and change the data value of a variable. Using Connected Components
Workbench software, you can specify which variables in the program can be
viewed and edited through the 2080-REMLCD module.
See
View and Edit Variable Values through the Remote LCD on page 68
.
Security
Activate, deactivate and change password protection.
Advanced Set
System Info
View system information such as operating
systems series and firmware revision.
Fault Code
View controller fault code information.
LCD Setup
Adjust LCD contrast, backlight color and
push button.
Clock Setup
The real-time clock and daylight saving time.
Language
Change menu language to French, Italian,
Spanish, and Chinese.
Analog Calibration
Configure calibration parameter of embedded
analog inputs.
PwrUp Behavior
Configure controller mode on powerup.
Memory Card
Access the microSD card.
ENET Cfg
View and change the Ethernet port configuration.
Operational Limit on 2080-REMLCD
Operation
PROG Mode
RUN Mode
Variable Edit
NO
YES
Analog Calibration
YES
NO
Controller → Memory Card
YES
NO
Memory Card → Controller
YES
NO
Others
YES
YES
