Calculate for Thermistor Resistance
While connecting Analog input to thermistor as shown in previous diagram,
calculate input voltage using the following equation:
Where:
Vi = Voltage input (±5% without calibration; ±2% with calibration)
Ri = Resistance input (14.14 K
Ω ±2%)
Rt = Thermistor resistance (10 K
Ω Thermistor is recommended)
Vref = 10V ±0.5V
To calculate for thermistor resistance, use the following equation.
Calibrate Thermistor
1.
Connect a resistor (10 K
Ω is recommended) across Vref and Analog
Input 00 of your Micro820 controller following the diagram,
. The resistor is measured as Ri using a precision
multimeter.
2.
Calculate the ideal counts (C1) for resistor (Ri) following this equation:
C1 = 14.14 K
Ω / (14.14 KΩ + Ri) * 4095
3.
Read the actual counts (C2) of Analog Input 00 from Connected
Components Workbench.
4.
Calculate for calibration Gain.
Gain = C1/C2
For example:
If Ri is measured as 10.00 K
Ω, then
C1 = 14.14 / (14.14 + 10.00) * 4095 = 2399 counts;
C2 is read from Connected Components Workbench as 2440; so
Gain = 2399/2440 = 98% .
IMPORTANT
Micro820 controllers support 10 KΩ type thermistors.
In order to get the best results, the system must be calibrated.
