Editing a Procedure

Chapter 7

7Ć13

The 1775-S4B scanner deletes the first two lines of @EXAMPLE, revises
the procedure line numbers, and returns:

P ‘LINE 2’
*

Definition: To exit the edit mode and return to the command mode.

Abbreviation: E

Format: E [ENTER]

Description: The exit command takes the 1775-S4B scanner out of the
edit mode, and returns the S4B> prompt.

Example using the exit edit mode command:

To exit the edit mode, just enter E:

* E [ENTER]

The 1775-S4B scanner returns the S4B> prompt:

You can use the 1775-S4A scanner to edit any type of message in the
message area of memory. If you connect an industrial terminal to the
1775-S4A scanner, you could edit one report generation procedure while
the 1775-S4B scanner executes another procedure.

CAUTION: Do not attempt to execute or edit a report
generation procedure that is being executed or edited by another
scanner. Unpredictable results may occur.

To enter the message edit mode on the 1775-S4A scanner, connect the
industrial terminal to the 1775-S4A scanner, and enter the following at the
$ sign:

ME, MR, [ENTER]

ME is the message edit command. MR stands for a message in the report
generation section of the message area. You could also enter:

MA for assist
MT for terminal

7.3.10
Exit Edit Mode

7.4
Editing Messages with a
1775ĆS4A Scanner
