Installing Your 1775ĆS4B Scanner
Chapter 3
3Ć8
Figure 3.8
I/O Channel Connections
НН
НН
НН
I/O
Scanner
Module
Swing Arm
(Car. No. 1775-WA)
I/O Adapter
Module Field
Wiring Arm
(Cat. No. 1771-WB)
I/O Adapter
Module Field
Wiring Arm
(Cat. No. 1771-WB)
Terminator
(Cat. No.1770-XT)
Twinaxial
Cable
(Cat. No. 1770-CD)
Terminator
(Cat. No. 1770-XT)
Blue
Shield
Clear
Blue
Shield
Clear
Blue Blue
Shield Shield
Clear Clear
Optional
User-supplied
Pushbutton
for I/O Chassis
Restart
Optional
User-supplied
Pushbutton
for I/O Chassis
Restart
10,000 cable ft or
3048 cable m maximum
НН
НН
In this chapter, you read installation procedures for:
Connecting an RS-232-C device to channel 5 for report generation
Connecting I/O chassis to the terminal swing arm for I/O scanning
Before you begin operating the 1775-S4B scanner, we suggest that you
double check all connections.
The next chapter describes LIST selections for the 1775-S4B scanner.
3.4
Chapter Summary
