background image

Logical Addressing for Report Generation

Chapter 6

6Ć2

Some examples appear below:

Data Table Address

Description

$B1:5

This address specifies binary file, 1, word 5.

$D0:1 or $D:1

These addresses specify the same address, decimal file 0

word 1. If you are specifying file 0, you need not enter a zero

after the section specifier.

$TPRE:57

This address specifies the preset of timer 57.

$B1:5/12

This address specifies binary file 1, word 5, bit 12 decimal.

$B1:5/12 or $B1:5/014

Both addresses specify binary file 1, word 5, bit 12 decimal. In

the second example, 014 represents the octal value for 12. To

enter a value in octal, enter a zero before the value.

Table 6.A

Data Table Section Specifiers

Section Specifier

Extended Address

Data Table Section

O

I

T

C

N

F

D

B

A

H

P

S

3.1.1

3.1.2

3.1.3

3.1.4

3.1.5

3.1.6

3.1.7

3.1.8

3.1.9

3.1.10

3.1.12

3.1.13

Output

Input

Timers

Counters

Integers

Floating Point

1

Decimal

Binary

ASCII

High Order Integers

Pointers

1

Status

1

You can only access these sections through extended addressing

Figure 6.1

Bit Numbering Formats

017 016 015 014 013 012 011 010 07 06 05 04 03 02 01 00

17 16 15 14 13 12

11

10 07 06 05 04 03 02 01 00

15 14 13 12

11

10

9

8

7

6

5

4

3

2

1

0

For report generation, always enter a leading

zero to maintain the octal addressing format

for compatibility with ladder diagram program

addressing and I/O terminal numbering.

The bit numbering

format within a

PLCĆ3 memory

word address

(ladder diagram

programming).

Alternately, by not entering leading

zeros, bits can be addressed in a

decimal format for report generation
