Formatting Module Data (WRITES)

Chapter 7

7Ć15

Figure 7.17

PID Band Word

50065

This value times two is the PID band,

BCD or binary

9.999 inch or 99.99 mm max

15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

Deadband (words 13 and 42)

The deadband parameter lets you select an error range on either side of a
commanded endpoint where the integral term of the PID algorithm doesn’t
change.

Figure 7.18

Deadband

50064

Position

Deadband

Endpoint

The module uses the deadband only after the axis crosses the endpoint. The
deadband helps reduce oscillations around the endpoint.

Figure 7.19

Deadband Word

50066

This value times two is the deadband,

BCD or binary

9.999 inch or 99.99 mm max

15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...

..

.

..

.
...
