Rockwell Automation 1772-LS_LSP,D17726.8.6 PROG/OPER MANUAL-MINI PLC-2/05 User Manual
Page 279
Quick Reference
Appendix C
CĆ23
Table C.V
Industrial Terminal Control Codes
Control Code
Key Sequence
Function
[CTRL][P]
[Column#][;]
[Line#][A]
Positions the cursor at the specified column and line number.
[CTRL][P][A] will position the cursor at the top left corner of the screen.
[CTRL][P][F]
Moves the cursor one space to the right.
[CTRL][P][U]
Moves the cursor one line up in the same column.
[CTRL][P][5][C]
Turns cursor on.
[CTRL][P][4][C]
Turns cursor off.
[CTRL][P][5][G]
Turns on graphics capability.
[CTRL][P][4][G]
Turns off graphics capability.
[CTRL][P][5][P]
Turns Channel C outputs on.
[CTRL][P][4][P]
Turns Channel C output off.
[CTRL][1]
Horizontal tab that moves the cursor to the next preset 8th position.
[CTRL][K]
Clears the screen from cursor position to end of screen and moves the cursor
to the top left corner of the screen.
Key Sequence
Attribute
1
[CTRL][P][0][T]
Attribute 0 = Normal Intensity
[CTRL][P][1][T]
Attribute 1 = Underline
[CTRL][P][2][T]
Attribute 2 = Intensify
[CTRL][P][3][T]
Attribute 3 = Blinking
[CTRL][P][4][T]
Attribute 4 = Reverse Video
Any three attributes can be used at one time using the following key sequence:
[CTRL][P][Attribute #][;][Attribute #][;][Attribute #][T]
