Rockwell Automation 1772-LS_LSP,D17726.8.6 PROG/OPER MANUAL-MINI PLC-2/05 User Manual
Page 135
Sequencers
Chapter 12
12-9
Position the cursor on the words SEQUENCER INPUT. Use the arrow
keys to move the cursor.
[DISPLAY]
The display appears in the lower left hand corner of the screen.
0
BINARY DATA MONITOR
SEQUENCER INPUT
STEP: 001
COUNTER ADDR: 200
SEQUENCER LENGTH: 006
FILE: 400Ć 413
INPUT ADDR: 110 201
DATA: 00000000 00000000 00000000 00000000
MASK ADDR: 070 701
DATA: 00000000 00000000 00000000 00000000
STEP
WORD 1
WORD 2
001
002
003
004
005
006
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
DATA: 00000000 00000000
The cursor is located on the first digit of DATA in the Command Buffer.
The digits in step 1 for word 1 are intensified.
