Sequencers

Chapter 12

12-11

00000010 00000000

[INSERT]

BINARY DATA MONITOR

SEQUENCER INPUT

STEP: 001

COUNTER ADDR: 200

SEQUENCER LENGTH: 006

FILE: 400Ć 413

INPUT ADDR: 110 201

DATA: 00000000 00000000 00000000 00000000

MASK ADDR: 070 701

DATA: 00000000 00000000 00000000 00000000

STEP

WORD 1

WORD 2

001

002

003

004

005

006

00000010

00000000

DATA: 00000010 00000001

BINARY DATA MONITOR

SEQUENCER INPUT

STEP: 001

COUNTER ADDR: 200

SEQUENCER LENGTH: 006

FILE: 400Ć 413

INPUT ADDR: 110 201

DATA: 00000000 00000000 00000000 00000000

MASK ADDR: 070 701

DATA: 00000000 00000000 00000000 00000000

STEP

WORD 1

WORD 2

001

002

003

004

005

006

00000010

00000000

00000001

00000000

DATA: 00000010 00000001

Cursor down one line. The cursor is on the first digit of DATA in the
command buffer. The digits in step 3 for word 1 are intensified.

Continue adding your data.

003:

00000010 00010001

004:

00000010 00010001

005:

00000010 01000001

006:

00000010 00000000

To add data to WORD 2 press [SHIFT][

→

|] and cursor up [

↑

] or down [

↑

]

as desired.

Do not press [CANCEL COMMAND]. The next example uses this data to
add a mask.
