Rockwell Automation 1772-LS_LSP,D17726.8.6 PROG/OPER MANUAL-MINI PLC-2/05 User Manual
Page 144

Sequencers
Chapter 12
12-18
Cursor down one line. The cursor is on the first digit of DATA in the
command buffer. the digits in step 3 for word 1 are intensified.
Continue adding data:
003:
00000010 00010001
004:
00000010 00010001
005:
00000010 01000001
006:
00000010 00000000
To add data to WORD 2 press [SHIFT][
→
] and cursor up [
↑
] or down [
↓
]
as desired.
Do not press [CANCEL COMMAND]. The next example uses this data to
enter a mask.
[DISPLAY]
The screen does not change.
000
BINARY DATA MONITOR
SEQUENCER INPUT
STEP: 001
COUNTER ADDR: 200
SEQUENCER LENGTH: 006
FILE: 600Ć 613
DATA:
MASK ADDR: 075 076
DATA: 00000000 00000000
STEP
WORD 1
WORD 2
001
002
003
004
005
006
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
DATA: 00000000 00000000
OUTPUT ADDR: 012 013
00000000 00000000 00000000 00000000
00000000 00000000
The cursor is on the first digit of DATA in the command buffer. OUTPUT
ADDR 012, DATA is intensified. You can add additional data.
Cursor down one line. MASK ADDR 075, DATA is intensified.
