Table C.K
File Instructions
Key Sequence 1770-T3 Display Instruction Notes
FILE
10
EN
File to File Move
Counter Addr:
Position:
File Length:
File A:
File R:
001
001
110Ć 110
110Ć 110 DN
030
Rate per Scan 001
030
17
030
15
Output Instruction.
Modes: Complete, Distributed and Incremental.
Counter is internally incremented by the instruction.
Requires 5 words of user program.
FILE
11
Word to File Move
Counter Addr:
Position:
File Length:
Word Addr:
File R:
001
001
010
110Ć 110
DN
030
030
15
Output instruction.
Counter must be externally indexed by user program.
Data is transferred every scan that rung is true.
Requires 4 words of user program.
FILE
12
File to Word Move
Counter Addr:
Position:
File Length:
File A:
Word Addr:
001
001
110Ć 110
010
DN
030
030
15
Same as word-to-file.
NOTE: Numbers shown are default values. Numbers in shaded areas must be replaced by user-entered values. The number of
default address digits initially displayed (3 or 4) will depend on the size of the data table.
To access the Data Monitor Display, enter all instruction parameters. Press key sequence:
[DISPLAY][0] for the binary monitor mode;
[DISPLAY][1] for the hexadecimal monitor mode.
This Value: Stores the:
Counter Address Address of the instruction's file position in the accumulated value
area of the data table
Position Current word being operated upon (accumulated value of the
counter)
File Length Number of words in the file (preset value of the counter)
File A Starting address of the source file
File R Starting address of the destination file
Word Address Address of the source word or destination word outside of the file
Rate Per Scan Number of data words moved per scan
