Sequencers

Chapter 12

12-12

[DISPLAY]

The screen does not change.

000

BINARY DATA MONITOR

SEQUENCER INPUT

STEP: 001

COUNTER ADDR: 200

SEQUENCER LENGTH: 006

FILE: 400Ć 413

INPUT ADDR: 110 201

DATA:

MASK ADDR: 070 701

DATA: 00000000 00000000 00000000 00000000

STEP

WORD 1

WORD 2

001

002

003

004

005

006

00000010

00000000

00000001

00010001

01000001

00000000

DATA: 00000000 00000000

00000000 00000000

The cursor is on the first digit of DATA in the command buffer. INPUT
ADDR 110, DATA is intensified. You can enter additional data.

Cursor down one line. MASK ADDR 070, DATA is intensified.

11111111 00000000

The screen does not change.

[INSERT]

BINARY DATA MONITOR

SEQUENCER INPUT

STEP: 001

COUNTER ADDR: 200

SEQUENCER LENGTH: 006

FILE: 400Ć 413

INPUT ADDR: 110 201

DATA:

MASK ADDR: 070 701

DATA: 00000000 00000000 00000000 00000000

STEP

WORD 1

WORD 2

001

002

003

004

005

006

00000000

DATA:

00000000 00000000

11111111 00000000

[CANCEL COMMAND]

To display your rung.

00000010

00000000

00000001

00010001

01000001

00000000
