Data Transfer File Instructions
Chapter 11
11-16
Notice that file R’s POSITION has not changed.
Now practice by changing POSITION 006 of file A to 7777.
Important: If you want to change the data in FILE R, you follow the same
procedure. To move your cursor to file R press the [SHIFT}, [
→
→
].
Purpose: Duplicates and transfers the data of a word from the data table to
a specified word within a file.
Programmed as an output instruction; requires four words of the user
program area. Your program must externally index the counter.
When the rung goes:
True - Data from a designated word address in the data table is transferred
to the selected position in the source file.
False - No action is taken.
Keystrokes: You enter a word to file move by performing the
following steps.
[FILE]
11
The screen does not change.
WordĆToĆFile Move
Counter Addr:
Position:
File Length:
30
001
001
DN
Word Addr:
File R:
010
110-110
030
15
0
Parameters: The procedure for entering the parameters for a word to file
move is the same as the procedure for a file to file move.
Purpose: Duplicates and transfers the data of a word within your source
file to a specified word elsewhere in the data table.
Programmed as an output instruction; requires four words of the user
program area. Your program must externally index the counter.
Word to File Move
File to Word Move
