Math Instructions
Chapter 10
10Ć21
4. Enter if appropriate.
5. Press -[G]-.
6. Enter
7. Enter if appropriate.
The second group of steps you perform enters the branch for the number to be
converted (term F).
1. Open the rung. Press the branch start key [ ].
2. Press -[G]-.
3. Enter
4. Enter if appropriate.
5. Close the branches. press the branch end key [ ].
6. Close the rung. Press [SHIFT][EAF].
7. Enter 14 (function number).
8. Enter 010 (data address).
9. Enter .
Editing a Completed Rung
Operand and Result: Follow the editing procedures for a Get instruction.
EAF Instruction: You edit an EAF instruction to change an address by
performing the following steps.
1. Press [SHIFT][EAF].
2. Enter 14 (function number).
3. Enter 010 (data address).
4. Enter .
We showed you how to program different types of math functions. The next
chapter tells how to transfer data files.
Chapter Summary
