Data Transfer File Instructions
Chapter 11
11-7
Use the following illustration as you read about each file instruction.
Key Sequence 1770-T3 Display Instruction Notes
EN
FileĆToĆFile Move
Counter Addr:
Position:
File Length:
030
001
001
DN
File A:
File R:
Rate Per Scan:
110-110
110-110
001
030
17
030
15
WordĆToĆFile Move
Counter Addr:
Position:
File Length:
030
001
001
DN
File R:
Word Address:
110-110
010
030
15
FileĆToĆWord Move
Counter Addr:
Position:
File Length:
030
001
001
DN
File A: 110-110
030
15
Word Address: 010
FILE
10
FILE
FILE
11
12
Output instruction.
Modes: Complete, distributed, and incremental.
Counter is internally incremented by the instruction.
Requires 5 words of user program.
Output instruction.
Counter must be externally indexed by user program.
Data is transferred every scan that rung is true.
Requires 4 words of user program.
Same as word-to-file.
IMPORTANT: Numbers shown are default values. Numbers in shaded areas must be replaced by userĆentered values. The number of 0 default
address digits initially displayed (3 or 4) will depend on the size of the data table.
Here is an explanation of each value:
This Value: Stores the:
Counter Address Address of the instruction's file position in the accumulated value
area of the data table
Position Current word being operated upon (accumulated value of the
counter)
File Length Number of words in the file (preset value of the counter)
File A Starting address of the source file
File R Starting address of the destination file
Word Address Address of the source word or destination word outside of the file
Rate Per Scan Number of data words moved per scan
