Quick Reference
Appendix C
CĆ16
Table C.O
Editing Functions
1
Function Key Sequence Mode Description
Inserting a condition
instruction
[INSERT]
(Instruction)
(Address)
or
[INSERT][ ]
(Instruction)
(Address)
Program Position the cursor on the instruction that will precede the
instruction to be inserted. Then press key sequence.
Position the cursor on the instruction that will follow the
instruction to be inserted. Then press key sequence.
Removing a condition
instruction
[REMOVE]
(instruction)
Program Position the cursor on the instruction to be removed and press
the key sequence.
Inserting a rung [INSERT]
[RUNG]
Program Position the cursor on any instruction in the preceding rung
and press the key sequence. Enter instructions and complete
the rung.
Removing a rung [REMOVE]
RUNG]
Program Position the cursor anywhere on the rung to be removed and
press the key sequence.
IMPORTANT: Only addresses corresponding to output
energize, latch and unlatch instructions are cleared to zero.
Change data of a word or
block instruction
[INSERT]
(Data)
Program Position the cursor on the word or block instruction whose data
is to be changed. Press the key sequence.
Change the address of a
word or block instruction
[INSERT]
(first Digit)
[ ← ]
(Address)
Program Position the cursor on a word or block instruction with data and
press [INSERT]. Enter the first digit of the first data value of the
instruction. Then use the [ ] and [ ]key as needed to cursor up
to the word address. Enter the appropriate digits of the
word address.
Online programming [SEARCH]
[5][2]
Initiates online programming.
Replace an instruction or
Change address of an
instruction without data
[Instruction]
(Address)
Program Position the cursor on the instruction to be replace or whose
address is to be changed. Press the desired instruction key (or
key sequence) and the required address(es).
Online Data Change [SEARCH]
[5][1]
(Data)
[RECORD]
[CANCEL
COMMAND]
Run/Progra
m
Position the cursor on the word or block instruction whose data
is to be changed. Press sequence. Cursor keys can be used.
Press [RECORD] to enter the new data into memory.
To terminate online data change.
All editing functions [CANCEL
COMMAND]
Program
Run/Progra
m
Aborts the operation at the current cursor position.
These functions can also be used during online programming.
When bit address exceeds 5 digits, press the [EXPAND ADDR] key before entering address and enter a leading
zero if necessary.
